2

整機重量overall weight

10000kg

3

斗容量bucket capacity

1.8-2.5m3

4

最大牽引力maximum traction force

98KN

5

最大掘起力maximum breakout force

120KN

6

最大爬坡能力maximum grade ability

30℃

7

最大卸載高度maximum dump height

3100mm

8

最大卸載距離maximum dump reach

1130mm

9

整機外形尺寸overall dimension (L×W×H)

7120*2375*3230mm

10

最小轉彎半徑minimum turning radius

5464mm

發動機

     Engine

11

型號model

Deutz enginesWP6G125E22

12

型式type

直列、水冷、四沖程、直噴

Vertical, in-line,    water cooled, 4-stroke diesel engine

13

汽缸數-缸徑*行程

     NO. of cylinder-bore*stroke

6-108*125

14

額定功率 rated power

92kw

15

最大扭矩 maximum torque

500N.m

16

最低燃油消耗率min. fuel-consume ratio

≦210Kw/h

傳動系統

     Transmission system

17

變矩器型式      torque    converter

YJ315-X

18

變速箱型式 gearbox mode

定軸常嚙合式Power shaft normally engaged straight gear

19

檔位數 gears

前進檔4個，倒退檔2個

4 forward  2 reverse

20

最高車速maximum speed

38km/h

驅動橋Drive axles

21

主減速式：main reducing spiral

螺旋傘齒輪一級減速bevel gear grade 1reduction

22

輪邊減速型式decelerating mode

一級行星減速

Planetary reduction    grade 1

23

軸距  wheel base (mm)

2740mm

24

最小離地間隙  ground    clearance

400mm

液壓系統Hydraulic system

系統工作壓力system working pressure

18MPa

25

三項和  total time

9.3±0.5s

制動系統

     Brake system

26

行車制動 service brake

氣頂油鉗盤式四輪制動

air assist disc brake    on 4 wheels

27

駐車制動  parking brake

手動嵌盤式Manual disk brake

輪胎

     Tyre

28

規格  type    specification

17.5-25

29

前輪氣壓  front tyre    pressure

0.4Mpa

30

后輪氣壓   rear tyre    pressure

0.35Mpa
