2

整機重量overall weight

19400KG

3

額定斗容 rated bucket capacity

3.3--4.5m3

3

最大牽引力maximum tractive force

158KN

4

最大崛起力maximum breakout force

204KN

5

整機外形尺寸overall dimension (L×W×H)

8250×3100×3400mm

6

最大爬坡能力maximum grade ability

30℃

7

最大卸載高度maximum dump height

3450mm

8

最大卸載距離maximum dump reach

1255mm

9

最小轉彎半徑minimum turning radius

6500mm

發動機Engine

11

型號model

濰柴 Weichai Steyr    WD10G240E21

12

型式type

直列\水冷\干缸套\直噴

     lnline     water cooling dry cylinder     injection

14

氣缸數-缸徑×行程N(yùn)o. of cylinder-bore/stroke

6－126×130mm

16

額定功率rated    power

175kw--2200r/min

傳動系統

     Transmission system

17

變矩器型式torque converter

雙渦輪四元件

18

變速箱型式 gearbox mode

行星式Planectary

19

檔位數gear shift

前進檔2個2 forward shift

倒退檔2個1 reverse shift

20

最高車速 maximum speed

38km/h

驅動橋Drive    axles

21

主減型式：main reducing spiral

螺旋傘齒輪一級減速

     bevel gear grade    1reduction

22

輪邊減速型式decelerating mode

一級行星減速

     planetary    reduction,grade 1

23

軸距 wheel base (mm)

3350mm

24

輪距 wheel tread

2250mm

25

最小離地間隙minimum ground clearance

450mm

液壓系統

     Hydraulic system

26

系統工作壓力system working pressure

18MPa

27

動臂提升時間 boom lifting time

6.15+0.25s

28

三項和 total time

10.65+0.5s

29

油箱容量  fuel    tank capacity

300L

30

鏟斗自動放平功能

     function of leveling    automatically

有 yes

制動系統

     Brake    system

31

行車制動 service brake

氣頂油鉗盤式四輪制動

     air over hydraulic    disc brake on 4 wheels

32

駐車制動 parking brake

手動環轂式制動 manual parking brake

輪胎

     Tyre

33

規格type specification

26.5-25

34

前輪氣壓 front tyre pressure

0.4Mpa

35

后輪氣壓 rear tyre pressure

0.35Mpa
